Introduction

Pitch canker disease, caused by the fungal agent Fusarium circinatum (= F. subglutinans f.sp. pini) (Niremberg and O'Donnell) (Hypocreales: Nectriaceae), has spread throughout the world. It is well reported that several insect species, mainly bark beetles, are capable of transmitting the pathogen (Fox et al. 1991; Hoover et al. 1995). Twig beetles of genus Pityophthorus Eichhoff (Coleoptera: Curculionidae: Scolytinae) have been traditionally considered as a secondary bark beetles group, due to their life habits and development in branches of dead and decaying trees (Bright 1981; Wood 1982). However, P. setosus and P. carmeli in California (Storer et al. 2004; Sakamoto et al. 2007) and P. pubescens (Marsham) in the Basque Country (northern Spain) (Romón et al. 2007) have been associated with F. circinatum.

Little is known about the biology of P. pubescens. According to previous research, it is considered as the only species of the genus inhabiting P. radiata stands of the Basque Country (López et al. 2007; López 2010), and it breeds in a broad number of Pinus L. (Pinales: Pinaceae) species (Balachowsky 1949; Pfeffer, 1976). It seems to show preference for host fresh tissues, according to the avoidance it exhibits to 4,6,6-trimethylbicyclo-[3.1.1]hept-3-en-2-one ((1S, 4S)-(-)-- verbenone) (Romón et al. 2007). However, there is a lack of knowledge about the biology and chemical ecology of the species.

Evidence of (2R, 5S)-2-(1-hydroxy-1-methylethyl)-5-methyltetrahydrofuran [hereafter (E)-(+)-pityol] as an aggregation pheromone component has been presented by López et al. (2011). Results obtained via effluvia collection revealed that both sexes emit (E)-pityol, although neither enantiomeric composition nor differences in emissions between sexes were elucidated. Moreover, behavioral assays in Y-tube olfactometer showed a stronger attractive effect on males (López et al. 2011). Taking into account these previous results, the main objective of our study was to determine the response of P. pubescens to (E)-(+)-pityol and the racemic mixture in different Pinus spp. stands of the Basque Country, in order to provide insight into the aggregation behavior of the species, and in the second instance, to infer the breeding behavior of the species through the observation of gallery systems.

Materials and Methods

Field assays

Two assays were carried out in four different Pinus spp. mature stands (ca. 30–35 years) of similar area in the Basque Country during 2011. The first trapping assay was conducted from 1 May to 30 June 2011, whereas the second one took place from 15 July to 15 September. This temporal frame was set due to the flight periods of P. pubescens in these months (S. López unpublished data). Three eight-unit Lindgren multiple funnel traps (Econex S.L.,  www.e-econex.com), 106 cm height, were placed in each stand. Sampling localities and their geographic coordinates are detailed in Table 1. Each trap was hung between two adjacent trees, with the top of the trap at 2 m above the ground and the distance between traps at least 75 m. One trap was set as a blank control, whereas the other two traps were baited either with (E)-(+)-pityol or the racemic mixture. Releasing devices consisted of one 1.5-mL capped plastic microcentrifuge vial (VRW International,  www.vwr.com) containing 2.5 µl of the attractant. After sealing them, caps were pierced with a number 2, heated insect pin (Dallara et al. 2000). The vials were refilled every week, and traps were re-randomized every week. Fifty mL of propylene glycol (propane 1,2-diol) (99%) (Panreac,  www.panreac.com) were added to each trap cup in order to kill and preserve captured insects. Insects caught were removed every week during the two months (n = 8 weeks, considered as replicates), taken to the laboratory, and identified under a Leica MZ95 stereo microscope (Leica Microsystems,  www.leica-microsystems.com) with the aid of identification keys (Balachowsky 1949; Pfeifer 1976). Gender was determined based on the presence of yellowish hairs on the frons, a typical characteristic of females (Pfeffer 1976) (Figure 1). Voucher specimens were deposited at the Entomology Collection of the NEIKER-Basque Institute for Agricultural Research and Development, Basque Country, Spain.

Table 1.

Pinus spp. stands sampled during field trapping with (E)-(+)-pityol and racemic (E)-pityol in different localities in the Basque Country (Northern Spain).

Results

Field assays

Apart from P. pubescens, no other bark beetle species were found in multiple funnel traps. A total of 9,121 P. pubescens were caught during field trapping from May to June, whereas 8,241 were trapped from July to September. Mean sex ratio, expressed as the percentage of males caught, for each sampling period and Pinus spp. stand is shown in Table 2. Twoway ANOVA revealed significant differences within sexes in all Pinus spp. stands, both in May–June (P. radiata F5,42 = 326.12, p < 0.001; P. sylvestris F5,42= 89.27, p < 0.001; P. pinaster F5,42 = 221.37, p < 0.001; P. nigra F5,42= 51.43, p < 0.001) and July–September (P. radiata F5,42= 340.84, p < 0.001; P. sylvestris F5,42 = 76.30, p < 0.001; P. pinaster F5,42 = 235.75, p < 0.001; P. nigra F5,42= 45.99, p < 0.001). In all these cases male catches were significantly higher. Significant differences were found between (E)-pityol baited traps and the blank control, although there were no differences between (E)-{+)-pityol and the racemic mixture in both sexes and experiments (Table 3, 4).

Table 2.

Mean sex ratio data (± SEM), expressed as percentage of male catches in (E)-pityol baited multiple-funnel traps, for both field-trapping periods and Pinus spp. stand.

Branch dissection

Of 147 examined galleries that contained at least one P. pubescens, 108 (73.46%) contained both a male and female, whereas 24 (16.32%) contained only one female. In addition, seven males (4.76%) were found alone in a gallery, four galleries (2.72%) were found to have two males and one female, three had two males and two females (2.04%), and only one had one male and two females (0.68%). It is remarkable that all beetles initiating galleries (24 females and seven males) were found until mid-May. On the contrary, galleries containing more than a single P. pubescens were collected at later dates. 102 galleries with a pair of beetles of both sexes had been excavated in the inner bark, with parental galleries showing a longitudinal pattern (Figure 2A). However, six galleries containing a pair were observed in the pith of relatively fresh branches (Figure 2B). Pair-occupied parental galleries showed a mean length of 6.57 ± 2.90 mm (range 2.28–14.19 mm).

Table 3.

Mean captures (± SEM) per week (n = 8 weeks/replicates) of male and female Pityophthorus pubescens in Lindgren funnel traps baited with (E)-(+)-pityol and racemic (E)-pityol in different Pinus spp. stands of the Basque Country (Northern Spain) ( 1 May—30 June 2011). Means within the same row followed by a different letter are significantly different at p ≤ 0.05 (Two-way ANOVA, followed by Tukey post-hoc tests).

Table 4.

Mean captures (± SEM) per week (n = 8 weeks/replicates) of male and female Pityophthorus pubescens in Lindgren funnel traps baited with (E)-(+)-pityol and racemic (E)-pityol in different Pinus spp. stands of the Basque Country (Northern Spain) ( 15 July—15 September 2011). Means within the same row followed by a different letter are significantly different at p < 0.05 (Two-way ANOVA, followed by Tukey post-hoc tests).

Discussion

Here, we provide evidence of the attractive effect of (E)-(+)-pityol and the racemic mixture on P. pubescens in field trapping. (E)-(+)-pityol is considered as a component of the aggregation pheromone of some species of the genus Pityophthorus. It was first isolated from male P. pityographus (Francke et al. 1987), and later from male P. carmeli, female P. setosus, and female P. nitidulus (Dallara et al. 2000). (E)-(+)-pityol is also known to be the female-produced sex pheromone of cone pine beetles, Conophthorus resinosae (Pierce et al. 1995), C. coniperda (Birgersson et al. 1995), and C. ponderosae (Miller et al. 2000). In all these cone beetle species, males are attracted strongly to (E)-(+)-pityol. In current work, attraction mediated by (E)-(+)-pityol and the racemic mixture did not differ, with both attracting significantly more male P. pubescens than females.

In contrast, the negative enantiomer of (E)pityol appears to be inactive to Pityophthorus spp. (Francke et al. 1987; Dallara et al. 2000; W. Francke, personal communication). European P. pityographus did not response to the mixture of racemic grandisol and (E)-(-)-pityol, whereas an attractive effect was observed when replacing (E)-(-)-pityol with (E)-(+)-pityol (Francke et al. 1987). Neither P. setosus nor P. carmeli were attracted to (E)-(-)-pityol (Dallara et al. 2000), and (E)-(-)-pityol did not interrupt the response of P. setosus to (E)-(+)-pityol (Dallara et al. 2000). Thus, this evidence and previous significant results with (E)-(+)-pityol and the racemic mixture (López et al. 2011) led to focus our work on these two compounds.

Traditionally, monogamy for these beetles has been defined as the reproductive behavior in which either sex may initiate the boring of a new gallery, and both sexes usually participate in the construction and care of the galleries (Wood 1982). The initiating sex is always constant. However, this term was redefined by Kirkendall (1983), who suggested a different point of view based on the mating system. According to Kirkendall, monogamy is considered as a mating system characterized by the presence of males in the gallery system until females finish ovipositing, whereas monogyny terminology is applied to those gallery systems made by the work of a single female (Kirkendall 1983). Hereafter, this terminology will be followed. Several genera of subtribe Pityophthorina, including Pityophthorus spp. complex, are characterized as harem polygynous, according to their mating system (Kirkendall 1983). Almost all Nearctic Pityophthorus species are considered within this category, but with some exceptions. Bright (1981) suggested that monogyny may be present in pith borer species, such as P. opaculus and P. puberulus, and evidence of monogyny has been found in P. setosus (Dallara et al. 2000), P. orarius, and P. fivazi (Kirkendall 1983). In addition, monogyny seems to be present in Palearctic P. henscheli, P. morosovi, P. traegardhi, and P. carniolicus (Pfeffer 1976). This reproductive behavior is also present in the closely related genus Conophthorus (Wood 1982). On the contrary, harem polygyny is characterized by (1) the presence of some female in a gallery system in which one female is already present and (2) a male-initiated gallery system and male-production of semiochemicals primarily attractive to females, whereas monogyny systems are based on a gallery system made by the work of a single female (Kirkendall 1983). Thus, taking into account these assertions, if one considered P. pubescens as polygynous, one would expect to find various females in a multiple arm gallery system around a nuptial chamber. Interestingly, our results are in contrast to this expected idea, and support the monogynous mating system hypothesis. First, parental galleries occupied by one female and one male consisted of a single and longitudinal gallery, with the absence of any star-shape nuptial chamber. This pattern of gallery habitation is similar to that found for P. setosus (Dallara 1997). In contrast, only one mother gallery was occupied by one male and two females, a typical pattern of polygynous. Secondly, most of the beetles that had initiated gallery construction were females, while gallery initiation was found for only seven males. It has been demonstrated that both sexes of P. setosus and P. carmeli are capable of tunneling in phloem of P. radiata bolts (Dallara et al. 2000). However, the proportion of male P. carmeli constructing galleries was found to be significantly higher than that of females. Conversely, a significantly greater proportion of female P. setosus excavated (Dallara et al. 2000). Our data are consistent with P. setosus, and could be evidence for considering females as the gallery initiation sex.

The sex ratio of beetles that responded to semiochemical trapping was strongly male-biased. Male catches either with the chiral (E)-pityol or the racemic mixture represented more than the 80% of the total catches in almost all Pinus spp. stands. These results are consistent with Dallara et al. (2000). In polygynous P. carmeli, females responded stronger than males to (E)-(+)-pityol and (5S, 7S)-(-)-7-methyl-1,6-dioxaspiro(4.5)decane (E)-(- )conophthorin) mixture, whereas in monogynous P. setosus, attraction to (E)-(+)-pityol alone was significantly higher in males than in females. Moreover, male P. pityographus, another polygynous species, is only attracted by the combination of cis-1-(2-hydroxyethyl)-1-methyl-2-(1-methyl-ethenyl)-cyclobutane ((±)-grandisol) and (E)-(+)-pityol (Francke et al. 1987). In fact, aggregation in these two polygynous species is not mediated in absence of any of the aggregation component. Our results resemble those observed for P. setosus, with a single component attracting significantly more opposite conspecifics.

According to our results, we propose the following host-attacking and mating sequence. Pioneering females would perform with the suitable-host seeking proccess and start the gallery construction. Then, the emission of (E)-pityol would attract males and a single male subsequently would enter the gallery initiated by each female. However, since both sexes appear to emit (E)-pityol, the biological implication of male-produced (E)-pityol remains still unclear. In Conophthorus spp., males emit (E)-(-)-conopthorin in order to repel and warn rival males (Birgersson et al. 1995). Nevertheless, it is unlikely that male P. pubescens would emit (E)-pityol as a warning signal for conspecific males, since we have demonstrated that (E)-pityol elicits a significant attractive effect on males. Thus, male-produced (E)-pityol requires further studies to disclose its biological activity.

In those gallery systems in which a pair of opposite conspecifics was present, eggs were observed. They had been deposited in small individual chambers on both sides of the mother gallery, and they were greyish, with oblong shape, 0.354 mm average length (range 0.303–0.399 mm, n = 58), and 0.545 mm average width (range 0.501–0.595, n = 58). Larvae were also present in some galleries, but no measures or biological data were taken. The mite species Pyemotes parviscolyti (Acari: Pyemotidae) was found in 56 breeding galleries. Female P. parviscolyti were found feeding on larvae and eggs of P. pubescens. Phoretomorphic females were also observed attached to the first pair of coxae of both sexes of P. pubescens.

In light of our results, we suggest using (E)-(+)-pityol or the more readily available and economical racemic mixture as a useful tool for monitoring populations of P. pubescens in Pinus spp. stands. In addition, it could even be used as a potential mate-finding disruptor in field due to its strong attractive effect on males. This kind of strategy was previously used with C. coniperda, with promising results (Trudel et al. 2004). There are commercially available devices containing the racemic mixture (95.4%) with a 0.2 mg/day release rate, which might correspond to about the equivalent of 200 female C. coniperda (De Groot and DeBarr 1998), and it could be as effective as the synthetic compounds. Further field studies should be carried out to determine if mate disruption in P. pubescens would be feasible.

Figure 1.

Pityophthorus pubescens head. (A) Male. (B) Female. Note the pubescent frons. High quality figures are available online.

Figure 2.

Pityophthorus pubescens gallery pattern. (A) Inner-bark excavated galleries, with egg niches across the gallery. Arrows indicate entrance holes. (B) Female P. pubescens boring into the pith (arrows). High quality figures are available online.
